Звуковая карта внешняя Antelope Audio Zen Q Synergy Core Thunderbolt Audio Interface

Analog
Analog Inputs
2 × Mic / Line Inputs / Hi-Z Inputs
2 x Line inputs / Hi-Z Inputs
48V phantom power and independent preamp gain for each input

Analog Outputs
1 × Monitor Out on TRS 1/4 Jacks, +20 dBu max, signal balanced, DC-coupled
1 × Line Out on TRS 1/4 Jacks, +20 dBu max, signal balanced, DC-coupled
2 × Stereo Headphone Outputs

Mic Preamp
EIN: -128 dBu (A-weighted)
Dynamic Range: -121 dB (A-weighted)
THD: -106 dB
Max input level: +20 dBu
Max Gain: 65 dB

Monitor
Max output level +20 dBu

D/A Monitor Converter
Dynamic Range: 127 dB (A-Weighed)
THD + N: -115 dB

D/A Line Out Converter
Dynamic Range: 127 dB (A-Weighed)
THD + N: -115 dB

A/D Converter
Dynamic Range: 122 dB
THD + N: -116 dB

Digital
Digital Inputs
1 × S/PDIF
1 x ADAT IN (up to 8 channels @44.1/48.0
Digital Outputs
1 × S/PDIF

Computer I/O
1 × Thunderbolt 3

Power
Bus-powered through Thunderbolt 3 port

Clocking
Clocking System
4th Generation Acoustically Focused Clocking (AFC™)
64-bit DDS

Sample Rates (kHz)
44.1, 48, 88.2, 96, 176.4, 192

Interface - Physical Dimensions
198 х 137 х 57.5 mm
Weight: 800 g (approx.)

Box - Physical Dimensions
260 х 205 х 95 mm
Weight: 1 kg (approx.)

2.8″ IPS Screen


Note: Thunderbolt cable is not included.
